4V220-08 Air Pneumatic Solenoid Valve 5-Way 2-Position 1/4' Aluminum Alloy Internal E 12VDC 24VDC 110VAC 220VAC 0.15-0.8Mpa


Color: PC 12mm Fittings
Specification: DC24V
:
Translation missing: ar.product.general.sale_priceDhs. 29.71 AED

Translation missing: ar.product.general.description

SPECIFICATIONS

Brand Name: NoEnName_Null

Certification: None

High-concerned chemical: None

Model Number: 4V220-08

Motivity Type: Other

Origin: Mainland China

Type: Valves

Product Name:Solenoid Valve

Model No:4V220-08

Fluid: 40 Micron Filtered Air
Operation Type: Internal Piloted

Port Size:Air Inlet =Air Outlet=PT 1/4, Exaust =PT 1/8
Working Pressure:0.15~0.8MPa
Type;5 Way 2 Position
Power Consumption:AC 220V 6.0VA
Rated Current: 250mA
Temperature: 35°C
Maxi. Withstand Pressure:1.2MPa
Threaded Port Size(Approx)Big: 11mm / 0.433"
Small: 8.8mm / 0.346"
Overall Size(Approx):15.5 x 5.5 x 2.2cm / 6.1" x 2.2" x 0.9" (L*W*H)
Color:White, Black

Quantity: 1PCS 4V220-08 + 3Pcs Quick fittings + 2Pc Mufflers
