3 SLOT GRILL DIFFUSER 3

General product description:

Linear diffuser(Linear Slot Diffuser) – Single slot(1 Slot)
A high-quality, streamlined diffuser designed for central air conditioning systems, featuring a sleek, modern design that provides balanced air distribution and an elegant aesthetic. Suitable for villas, hotels, shopping centers, offices, and luxury projects. .

Key features:

• Modern linear design suitable for all types of interior decorations .
• Smooth and quiet air distribution without noise .
• Air can be directed at multiple angles via the Deflection Blade .
• Suitable for installation in gypsum ceilings .
• Lightweight and rust-resistant .
• Easy to disassemble, clean, and maintain .

Materials and manufacturing:

• Made of High -quality aluminum(Extruded Aluminum)
• Finishing Powder coat, scratch resistant – whiteRAL 9016
• Internal code The black blade design of the opening gives it a sleek look. .
• Thickness 1.0 – 1.2 mm ( depending on size) )

Product dimensions:

• Front size: 50mm
• Back size: 30mm
• an offer The opening 25 mm(1” Slot)
• Product length :Made to order

Technical specifications  :

• air flow rate From 70 to 150CFM per meter according to the required air speed .
• Noise level Low Noise ≤ 25 dB
• Operating pressure 0 – 30 Pa
• air direction Horizontal Air Supply
• Suitable for both hot and cold air conditioning .
• Two types are available: Supply and Return
• Available in different colors

Installation method:

• Concealed installation within the ceiling using Side Brackets .
• The possibility of joining pieces to obtain a longer length .
• Plenum Box can be added With/Without Volume Control Damper upon request .

Uses:

• residential villas
• Hospitality and hotel buildings
• Malls and shops
• Theaters and halls
• Offices and administrative headquarters
• Projects High-end Interior Design

Technical details:







Other options:

• Plenum Box can be added  upon request
• Volume Control Damper can be added upon request .

·         Different colors can be ordered

·         Multiple sizes can be ordered

·         Special rates are available for large projects and businesses.
