Description
General product description:
Linear diffuser(Linear Slot Diffuser) – Single slot(1 Slot)
A high-quality, streamlined diffuser designed for central air conditioning systems, featuring a sleek, modern design that provides balanced air distribution and an elegant aesthetic. Suitable for villas, hotels, shopping centers, offices, and luxury projects. .
Key features:
- Modern linear design suitable for all types of interior decorations .
- Smooth and quiet air distribution without noise .
- Air can be directed at multiple angles via the Deflection Blade .
- Suitable for installation in gypsum ceilings .
- Lightweight and rust-resistant .
- Easy to disassemble, clean, and maintain .
Materials and manufacturing:
- Made of High -quality aluminum(Extruded Aluminum)
- Finishing Powder coat, scratch resistant – whiteRAL 9016
- Internal code The black blade design of the opening gives it a sleek look. .
- Thickness 1.0 – 1.2 mm ( depending on size) )
Product dimensions:
- Front size: 50mm
- Back size: 30mm
- an offer The opening 25 mm(1” Slot)
- Product length :Made to order
Technical specifications :
- air flow rate From 70 to 150CFM per meter according to the required air speed .
- Noise level Low Noise ≤ 25 dB
- Operating pressure 0 – 30 Pa
- air direction Horizontal Air Supply
- Suitable for both cold and hot air conditioning .
- Two types are available: Supply and Return
- Available in different colors
Installation method:
- Concealed installation within the ceiling using Side Brackets .
- The possibility of joining pieces to obtain a longer length .
- Plenum Box can be added With/Without Volume Control Damper upon request .
Uses
- residential villas
- Hospitality and hotel buildings
- Malls and shops
- Theaters and halls
- Offices and administrative headquarters
- Projects High-end Interior Design
Technical details:
|
Item |
the details |
|
Type |
1 Slot Diffuser 1 SLOT GRILL DIFFUSER |
|
Number of openings |
1 slot |
|
Brand |
LP |
|
The structure |
All parts of the grill are made of aluminum. |
|
Aluminum thickness |
5 mm per frame |
|
front size |
50 mm |
|
Back size |
35mm |
|
hole size |
25mm |
|
height |
Made to order |
|
the color |
white color RAL 9016black color RAL 9005 |
|
Paint type |
High-quality powder coating |
|
Internal code |
Internal code available |
|
Air direction control |
Yes, code routing is possible. |
|
Available types |
SUPPLY & RETURN |
|
air flow rate |
70 to 150 CFM |
|
Noise level |
Low Noise ≤ 25 dB |
|
Operating pressure |
0 – 30 Pa |
|
|
|
|
Country of origin |
United Arab Emirates |
Other options:
- Plenum Box can be added upon request
- Volume Control Damper can be added upon request .
· Different colors can be ordered
· Multiple sizes can be ordered
· Special rates are available for large projects and businesses.
